 Aluminium Busbar



Electric Conduction Aluminum Bus bar (square edge)
3mm 3×15 3×20 3×25 3×30 3×40 3×50
4mm 4×10 4×20 4×25 4×30 4×40 4×45 4×50
5mm 5×20 5×25 5×30 5×35 5×40 5×50 5×60 5×80
6mm 6×20 6×30 6×40 6×50 6×60 6×80 6×100 6.3×50 6.3×80 6.3×100
7mm 7.6×80               6.3×76 6.3×63
8mm 8×11 8×30 8×40 8×50 8×60 8×63 8×80 8×100 8×120 8.1×74
10mm 10×30 10×40 10×50 10×60 10×63 10×80 10×100 10×120 10×125 10×140
10mm 10×150 10×160
12mm 12×60 12×80 12×100 12×120 12×125 12×150 12.5×125
14mm 14×80 14×100
15mm 15×100 15×120
16mm 16×100 16×125
20mm 20×80 20×100
Electric Conduction Aluminum Bus bar (round edge)
2mm R2×20
3mm R3×30 R3×40 R3×50 R3×60 R3×80 R3×100 R3×120 R3×160
4mm R4×25 R4×30 R4×40 R4×50 R4.7×151
5mm R5×30 R5×35 R5×40 R5×50 R5×60 R5×120
6mm R6×50 R6×60 R6×80 R6.3×63 R6×100 R6×120 R6×140 R6×160
8mm R8×40 R8×50 R8×60 R8×63 R8×80 R8×100
10mm R10×50 R10×60 R10×80 R10×100 R10×120 R10×125 R10×170 R10.4×25
12.5mm R12.5×80 R12.5×125     R16×125
Chemical compositions (%)
Alloy Si Fe Cu Mn Mg Cr Ni Zn Ga V Ti Ca Alu
1370 0.03 0.11 0.046 0.019 0.0005 0.0004 0.0041 0.0086 0.0164 0.0042 0.0095 0.0001 99.7455
1350 0.10 0.40 0.05 0.01 -- 0.01 -- 0.05 -- -- - 0.03 99.50
1060 0.25 0.35 0.05 0.03 0.03 -- -- 0.05 -- -- 0.03- -- 99.60
1070 0.20 0.25 0.03 0.03 0.03 -- -- 0.07 -- -- 0.03 -- 99.70




Packing Process :

Step 1 :  Placed neatly , the outside packing with plastic film and absolute cloth, keep dry and clean ;





Step 2 : There are three kinds of packing, below is the packing pictures :

Wooden box or wooden case packaging, the outside fixed with packing belt, safe and reliable ;
